Applications
- Residential Installations : These panels can be used on rooftops to provide clean energy for homes, reducing electricity bills and carbon footprints.
- Commercial Projects : Ideal for larger installations on commercial buildings, warehouses, and factories, helping businesses cut energy costs and meet sustainability goals.
- Utility-Scale Solar Farms : These high-efficiency panels are perfect for large solar farms, contributing significantly to the grid and supporting renewable energy targets.
- Agricultural Use : They can power irrigation systems, greenhouses, and other farm operations, promoting sustainable agriculture.
- Off-Grid Systems : Suitable for remote locations without access to the grid, providing reliable power for cabins, remote facilities, and emergency backup systems.
Features
- High Efficiency
- Half-Cut Cell Design
- Bifacial Technology
- Durability
- Positive Power
- Advanced Cell Technology
- 520W to 540W solar panels an excellent choice for both residential and commercial installations, offering high efficiency, reliability, and enhanced energy production.
UNLEASHING THE POWER OF HIMALAYAN SOLAR MODULES
Our solar modules are manufactured in state-of-the-art ISO-certified facilities, guaranteeing the highest quality standards and reliability.
With guaranteed positive tolerance, our solar modules deliver consistent and reliable power output, maximizing energy generation.
Our modules are designed to reduce equipment loss while optimizing power generation and maximizing solar potential.
Our solar modules are weatherproof and built to withstand harsh environmental conditions for long-term endurance.
Even in weak light conditions, our solar modules excel, delivering more power output and ensuring maximum efficiency.
We use high-grade raw materials in our manufacturing process, ensuring uncompromised quality and optimal performance.
Technical Specifications
| Solar Cell | 2094 mm x 1134 mm x 35 mm poly crystalline silicon solar cell |
| Front Cover | 3.2mm thick tempered glass |
| Back Cover | TPT/TPE film |
| Encapsulant | EVA film |
| Frame | Anodized aluminum alloy |
| Junction Box | IP68 rated |
| Connectors | MC4 or compatible connectors |
| Dimensions | 2094 mm x 1134 mm x 35 mm |
| Max. System Voltage | DC1000V (IEC) |
| Max. Series Fuse | 30A |
| Operating Temperature | -40℃+80℃ |
| Storage Temperature | -40℃+80℃ |
| Max. Wind/Snow Load | 2400Pa / 5400Pa |
| Application Class | Class A |
| Module Area(m2) | 1.94m2 |
| Weight | 26kg |
| Model | No of Cell | Cell Wattage | Short Circuit Current | Operating Voltage | Operating Current | Open Circuit Voltage | Module Efficiency | Max. Series Fuse Rating | Power Tolerance |
| - | - | (Wp) | (Isc) | (Vmp) | (Imp)A | (Voc) | % | - | + |
| HS-144M 540 | 144 | 4.52 | 14.35A | 40.47V | 13.17A | 49.53V | 21.35 | 20 | 5 |
| HS-144M 530 | 144 | 4.42 | 14.30A | 40.74V | 13.1A | 49.26V | 20.96 | 20 | 5 |
| HS-144M 520 | 144 | 4.42 | 14.21A | 40.04V | 12.5A | 48.99V | 20.56 | 20 | 5 |
Warranty
- 10 years for product defects in materials and workmanship
- 27 years linear power output warranty: 10 years at 90% of the minimal rated power output, 25 years at 80% of the minimal rated power output
- 80% of the minimal rated power output
Standard Test Condition
- All electrical parameters specified at Standard Test Conditions
- 25 degree C cell temperature
- 1000 W/m2 irradiance
- Air Mass(AM) 1.5
